Hexagon Bolts 10.9-K1-WS41-(HDG)-M24X100

Specs:
Thread type x nominal diameter (d1):
M24
Length (l1):
80 mm
Head height (k1):
15 mm
Standards:
EN 14399-4
Material:
Steel
Property class:
10.9
Surface:
Hot dip galvanized
k-class:
K1
Head details:
With large under head surface and large under head radius
External drive (s1):
WS41
Shaft diameter (ds):
24 mm
Thread length (metric thread) (b):
39 mm
Pitch:
3 mm
Min./max. pack thickness:
41-46 mm
Min./max. grip length:
49-54 mm
Area of application:
Steel construction
Suitable for:
High-strength friction connections in steel structures
Regulated area:
hEN 14399-1
Construction product:
Yes
Declaration of performance (EU-CPR):
Yes
RoHS-compliant:
Yes
