RRP $2,017.95
$1,284.14
SAVE $733.81 (36%)
Not Available In Store

Calculate Shipping

Cylinder capacity ton* : 10
Cylinder capacity kN: 101
Stroke (mm): 12
Cylinder Effective Area (cm2): 14.5
Oil capcity (cm3): 17
Collapsed height (mm): 43
Extended height (mm): 55
Outside diameter (mm): 82x55
Cylinder Bore diameter(mm): 42.9
Piston Rod diameter (mm): 38.1
Base to Advance Port (mm): 19
Load Cap Protrusion from Cylinder Body (mm): 1

(RFJ100)

SKU RFJ100
Barcode # 9310755037451
Shipping Weight 1.4000kg
Shipping Width 0.150m
Shipping Height 0.100m
Shipping Length 0.200m
