63mm SS liquid filled 1/4" BSPT rear entry 0-100 kp - 63mm 304 Stainless Steel Case, brass internals and entry. Liquid Filled.Crimped - GAU63R-100
SKU:GAU63R-100
RRP $73.92
$50.44
SAVE $23.48 (32%)
Not Available In Store
Calculate Shipping
GAU63R-100: 0 to 100 kpa (0 to 15 PSI)
Size 63mm (2 1/2")
Accuracy: +/- 1.6%
Range: Depends upon model
Work Pressure: 3/4 of full scale
Fluctuating pressure: 2/3 of full scale
Short Time Pressure: Full Scale
Operating Temperature: -10°C to 60°C
Media: Compatible gases and liquids
Housing: 304 Stainless Steel Case and crimped ring
Window: Polycarbonate
Liquid Filled: Glycerine
Bourdon Tube: Copper alloy
Movement: Copper alloy
Connection: Brass
Thread: BSPT
Scale: Dual Scale Kpa/Psi
Size 63mm (2 1/2")
Accuracy: +/- 1.6%
Range: Depends upon model
Work Pressure: 3/4 of full scale
Fluctuating pressure: 2/3 of full scale
Short Time Pressure: Full Scale
Operating Temperature: -10°C to 60°C
Media: Compatible gases and liquids
Housing: 304 Stainless Steel Case and crimped ring
Window: Polycarbonate
Liquid Filled: Glycerine
Bourdon Tube: Copper alloy
Movement: Copper alloy
Connection: Brass
Thread: BSPT
Scale: Dual Scale Kpa/Psi
(GAU63R-100)
| SKU | GAU63R-100 |
| Barcode # | 9310755067243 |
| Shipping Weight | 0.4000kg |
| Shipping Width | 0.100m |
| Shipping Height | 0.050m |
| Shipping Length | 0.100m |
