Chain Block 2000Kg X 3 Metre

APPLICATION :
To safely facilitate the lifting of heavy component objects or materials. Designed to meet and exceed the needs of all industrial, mining, rigging, automotive and marine lifting applications.
FEATURES:
Manufactured with industrial strength, impact resistant, hardened steel frame and gear-case
Unique 3 spur gear efficiency reduces required operator effort by 25 percent
Double guide rollers and pawl enhance safety, performance and reliability
Asbestos free friction disc
Fitted with industrial duty caged needle roller bearings on load sheaves
Rated grade 80 alloy steel load chain compliant to ASO 3077 and EN818-7
Load rated, drop forged, wide throat hooks with cast safety latches and bottom hook assembly 360° rotatable with thrust bearing
Powder coated finish for corrosion resistance
Can be close coupled to suitable girder trolley assembly (Grip part no 18145 suitable)
Complies to AS1418.2:1997 standard and also meets all pertinent world standards
including European E13157 - Proof tested 1.5 x W.L.L (working load limit )
Individual serial numbered test certificate supplied
SPECIFICATIONS:
Rated capacity: 2 tonne (2000kg)

Standard lift: 3 metresEffort required to lift rated load: 335 newtons
Packaged Dimensions (L x W x H):300 x 230x 190mm
Weight(nett): 18kg
