RC50, 45 kN Capacity, 16 mm Stroke, General Purpose Hydraulic Cylinder.

RRP $2,002.00

$1,365.65

SAVE $636.35 (32%)

Not Available In Store

Calculate Shipping

Maximum Operating Pressure: 700 bar
Capacity Class: 5 tonnage
Maximum Cylinder Capacity Advance:45 kN
Stroke: 16 mm
Collapsed Height A: 41 mm
Extended Height B: 57 mm
Return Type: Single-Acting, Spring Return
Plunger Type: Solid
Material: Steel
Cylinder Effective Area Advance: 6,4 cm2
Oil Capacity Advance: 10 cm3
Surface Treatment: Paint
Coupler:CR400 Coupler
Weight: 1,0 kg

(RC50)

SKU	RC50
Barcode #	9310755039691
Shipping Weight	1.0000kg
Shipping Width	0.100m
Shipping Height	0.080m
Shipping Length	0.150m
